Frame
|
Bianchi Infinito, Flat mount 140/160, PressFit 86.5x41 mm, Thru Axle 12x142 mm, Sram UDH compatible, Max chainring compatibility: 46-54T, Internal cable routing, Tire clearance: ETRTO 622-40 sizes 47-50-53-55-57-59-61 cm |
Fork
|
Bianchi Infinito, Flat mount disc 140/160, Thru axle, OLD: 100 mm, Steerer tube diameter: 1"1/8 |
Headset
|
Acros for internal cable routing |
Shifters
|
Shimano 105 Di2, shifter lever ST-R7170, caliper BR-R7170 |
Rearderailleur
|
Shimano 105 Di2, RD-R7150, 12sp |
Frontderailleur
|
Shimano 105 Di2, FD-R7150 |
Crankset
|
Shimano 105, FC-R7100, Hollowtech 2, 50x34T Crank length: 165 mm (47-50 cm); 170 mm (53-55 cm); 172.5 mm (57-59 cm); 175 mm (61 cm) |
Bb
|
Shimano SM-BB71-41B, press fit type for road |
Chain
|
Shimano CN-M7100 |
Sprocket
|
Shimano 105, CS-R7101 11-36T, 11-12-13-14-15-17-19-21-24-28-32-36T |
Brakes
|
Shimano BR-R7170 Hydraulic disc brake |
Brakelevers
|
Included in the shifter |
Wheels
|
Bianchi B 30R, alloy, internal channel width 23 mm, profile height 30 mm, 2 to 1 spoke pattern, j-bend spokes, black, HG11 body, weight: 1790 g |
Tire
|
Pirelli P7 Sport, 35-622, 60 TPI |
Stem
|
Bianchi AL6061, rise -7° Size: 90 mm (47-50 cm); 100 mm (53-55 cm); 110 mm (57-59 cm); 120 mm (61 cm) |
Handlebar
|
Bianchi Compact, AL6061, diameter 31.8 mm, reach 80 mm, drop 130 mm Size: 380 mm (47-50 cm); 400 mm (53-59 cm); 420 mm (61 cm) |
Tapehandlebar
|
Bianchi Hexagon tape, 2.5 mm thickness, black |
Seatpost
|
Bianchi Infinito, Countervail technology, full carbon, aero-flex shape length: 320 mm, 0 offset (47-53 cm); 350 mm, -20 mm offset (55-61 cm) |
Seatpostqr
|
Bianchi Custom |
Saddle
|
Bianchi Manganese Rail, length 260 mm, width 150 mm |
Rotor
|
Shimano RT-CL700 Center Lock, 160 mm |
