MOTOR
|
Bosch Performance Line BDU3460, 75 Nm - Purion 200 |
BATTERY
|
Bosch Powertube 600 Wh Horizontal |
FRAME
|
Bianchi T-Tronik X, aluminium, 12x148 mm rear thru axle, Post mount 180 disc brake type, Front travel 120 mm, Internal cable routing in steerer, 800 Wh battery compatible sizes SM-MD-LG-XL |
FORK
|
Suntour XCR34X, Air, 120 mm travel, Steerer tube 1,5" tapered, 34 mm stanchions, 15x110 Boost axle, Rotor: minimum 180 mm, maximum 203 mm |
HEADSET
|
FSA 1.5" for tapered fork steerer, Dual side internal cable routing |
SHIFTERS
|
Shimano Deore SL-M4100, Rapidfire Plus |
REAR DERAILLEUR
|
Shimano Deore, RD-M4120, 10sp, Shadow design |
CRANKSET
|
FSA CK-320/IS, Aluminium DieCast, Crank length: 170 mm |
CHAIN
|
KMC e10S EPT, Anti-Rust |
CASSETTE
|
Sunrace CSMS2, 11-42T |
BRAKES
|
Shimano Deore BR-MT410, 2 piston, resin pad |
BRAKE LEVERS
|
Shimano Deore BL-MT401 |
ROTOR
|
FRONT: Shimano SM-RT30, 203 mm / REAR: Saccon CDM80FD, 180 mm |
WHEELS
|
Velomann 622x30, 32 hole; Front hub: Shimano TC500 Thru axle; Rear hub: Shimano TC500 Thru axle |
TIRE
|
Obor Mike Bear, 29"x2,35", 60 TPI |
STEM
|
Velomann Viper0, alloy, Diameter 28.6 mm, Barbore 31,8 mm Size: 60 mm |
HANDLEBAR
|
Velomann Aluminium, Rise 15 mm, Barbore 31.8 mm, Width 740 mm Size: 740 mm |
GRIPS / EXTENSIONS
|
Herrmans Luna lock 130 mm |
SEATPOST CLAMP
|
Ursus Alloy, Quick Release, Diameter 34,9 mm |
SEATPOST
|
Velomann AL2014, Diameter: 31,6 mm, Seatback: 0 mm for size SM; Dropper, travel 125 mm for size MD-LG; Dropper, travel 150 mm for size XL |
SADDLE
|
Velomann Velomann Gnd Full-fit Start Up, Carbon-steel rail, 262 mm x 145 mm |
